SF-200
Print Safe
Direct-to-object printing for sensitive applications
SF-200 Specifications
Model | SF-200 | |
Printing method | Piezo ink-jet method | |
Media | Width | Max. 538 mm (21.2 in.) |
Length | Max. 360 mm (14.2 in.) | |
Thickness | Max. 100 mm (3.94 in.) | |
Weight | Max. 5 kg (11 lb.) | |
Printing width / length | Max. 508 (w) × 330 (l) mm (20 × 13 in.) | |
Printing resolution | Max. 1440 dpi | |
Ink | Type | Ink specified by Roland DG Corporation |
Colour | Five colours (Cyan, Magenta, Yellow, Black and White) |
|
Distance accuracy *1 | ±0.3% of distance travelled or ±0.3 mm (±11.8 mil), whichever is greater | |
Connectivity | Ethernet (10BASE-T/100BASE-TX, automatic switching | |
Power-saving function | Automatic sleep feature | |
Power requirements | AC100 to 240 V ± 10%, 1.1 A, 50/60 Hz | |
Power consumption | During operation | Approx. 81 W |
Sleep mode | Approx. 13 W | |
Acoustic noise level | During operation | 60 dB (A) or less |
During standby | 49 dB (A) or less | |
Other dimensions | 1202 (W) × 962 (D) × 549 (H) mm (47.3 × 37.9 × 21.6 in.) | |
Weight | 110 kg (242.5 lb.) | |
Environment | During operation | Temperature: 20 to 32°C (68 to 90°F) (22°C (72°F) or higher recommended), Humidity: 35 to 80% RH (no condensation) |
Not operating | Temperature: 5 to 40°C (41 to 104°F), Humidity: 20 to 80% RH (no condensation) | |
Included items | VersaWorks 6 RIP software, power cable, cleaning liquid, drain bottle, manuals, etc. |
*1 Temperature: 25°C (77°F), Humidity: 50% RH
Specifications, designs and dimensions listed may be subject to change without notice.
VersaWorks 6 System Requirements | ||
Operating system | Windows® 10 (32/64 bit), Windows® 8.1 (32/64 bit), Windows® 7 Ultimate / Professional (32/64 bit) | |
CPU | Intel® Core™2 Duo, 2.0 GHz or faster recommended | |
RAM | 2 GB or more recommended | |
Video card and monitor | A resolution of 1280 x 1024 or more recommended | |
Free hard-disk space (HDD/SSD) | 40 GB or more recommended | |
Hard-disk file system | NTFS format | |
Optical drive | DVD-ROM drive | |
Other | Internet connection recommended |
Consumables | |
Model | Description |
INKU-SF-220-CY | INKU SF Ink Cyan, 220 ml |
INKU-SF-220-MG | INKU SF Ink Magenta, 220 ml |
INKU-SF-220-YE | INKU SF Ink Yellow, 220 ml |
INKU-SF-220-BK | INKU SF Ink Black, 220 ml |
INKU-SF-220-WH * |
INKU SF INK, White, 220 ml |
SL-CL | Cleaning liquid, 200 ml |
Optional SF-200 Base Unit | |
Airflow | 100 - 200 m³/h |
Combined filter | Gas / HEPA filter |
Controls | Power on/off/ 2 x PID temperature controllers |
Monitoring | VOC. Filter Change Indicator |
Electronic supply |
240V |
Frequency | 50/60 Hz |
Full load current |
10A |
Estimated weight | 180 - 200 kg |
Heated drawer dimensions |
397 mm (w) x 617 mm (d) x 102 mm (h) |
Overall dimensions |
1210 mm (w) x 1023 mm (d) including spigot 995 mm / excluding spigot x 712 mm (h), 740 mm including top spigot |
Lockable / levelling castors |
x 4 |
Specifications, designs and dimensions listed may be subject to change without notice.
