UV-LED Flatbed Printer with Outstanding Price-Performance

VersaOBJECT
EU-1000MFNEW LED-UV Flatbed Printer
Start expanding your graphic horizons with the EU‑1000MF UV-LED Flatbed Printer

Print high-quality graphics at high speeds directly onto substrates up to 2,440 mm x 1,220 mm and with a maximum height of 95 mm with the VersaOBJECT EU-1000MF.

Print on PVC panels, foam panels, corrugated cardboard, aluminium plates and more.
Fast printing with four-colour/four-head and six-colour/six-head models.
Reliable, high-quality printing with high-density, low-cost E-US inks, a liquid-cooled LED lamp system, a four-zone vacuum bed, and many more advanced features.
Comes with VersaWorks 6 RIP software – Roland DG’s most powerful, intuitive RIP to date – which includes a host of useful features and tools that optimize efficiency, productivity, and convenience.

Download Brochure

Large Format Flatbed Printing
at the Price, Quality and Speed You Need

Whether you supply signage and graphics for shopfronts, events, corporate, interior decoration or any number of other applications, the VersaOBJECT EU-1000MF is a revolutionary way to print and create new business opportunities. Compatible with hundreds of substrates and delivers high-impact graphics, the EU-1000MF fits seamlessly into your workspace and offers the ease, speed, quality and value you need to take your business to the next level.

Print directly onto full panels of PVC, corrugated cardboard, foam boards, and other materials to produce large quantities of yard signs, shop signs, point-of-purchase displays, and promotions. Add satin or matte finishes for elegant 3D textures and raised effects.

With up to six print heads in a staggered configuration, 2.5-liter ink tanks, and a variety of print modes, you can increase your throughput considerably, printing large quantities of graphics onto sign and presentation panels.

Produce stunning contour-cut signage for shops, hotels, museums, exhibitions and other locations. With a four-zone vacuum bed, alignment markers, and other workflow features, printing on one or multiple panels is a breeze.

The high-volume output of the EU-1000MF lets you apply prints directly to ceramic tiles, acrylic panels and other applications to create wall, floor and display graphics in restaurants, shops, residences, hotels, exhibitions and more.

The EU-1000MF makes it simple to print stunning canvas wall art and even simulate oil painting brush strokes with the use of UV gloss ink.

UV inks are great for creating a wide range of wall graphic applications that can brighten up any interior space, from living rooms and nurseries to offices and shop fittings.

Everything You Need to Succeed

UV Flatbed Printer

Print high-quality graphics at high speeds directly onto the media.

VersaWorks 6 RIP

Power your workflow with our most intelligent RIP software to date

Economical E-US Ink

Get stunning results every time with economical E-US ink.

Roland DG Care Warranty

Secure your investment with industry-leading support

See specifications for all included items

Inexpensive Inks, Intuitive Operation

In addition to CMYK process colours, the new E-US inks are available in White and Clear Varnish on the 6C configuration,
delivering high-quality print results on hundreds of applications. The VersaOBJECT EU-1000MF offers a number of ink advantages for a
high-volume production UV flatbed operation.

	Easy Ink Loading Allows you to refill the 2.5L tanks as you go for high productivity, high volume printing.
	LCD ink level display Provides instant reference to ink status for fast, efficient refills in the middle of a print.

	Print at Low Costs Cost-effective inks when compared to other UV inks for large format flatbeds on the market.
	Increase the Life Cycle of Your White Ink Automatic agitation prevents white ink from settling in the tank to maintain consistent delivery.

Advanced Flatbed Technology
for Easy and Efficient Operation

Powerful and Advanced Flatbed Printing

High power technology of four or six print heads in a staggered two-row configuration.
Print in standard or high-quality modes to suit your production needs.

Electronic Vacuum Bed

While many competitive flatbed devices rely on manual air switches, the EU-1000MF has a four-zone electronic vacuum bed that automatically adds suction and support in selected areas.

Easy Handling of Substrates

Positive air pressure allows for secure, firm placement of heavy foils and substrates, allowing for easy loading and stable printing.

Substrate Alignment Pins

Achieve consistent panel and board positioning with media alignment pins in the corner of the flatbed, which pop up at the touch of a button for automatic alignment to the print origin point.

LED Lamps with Liquid Cooling

Liquid cooling dramatically increases the life cycle of your lamps, making the current process of your prints faster and more efficient.

Productivity Features

	Industrial Grade Casters and Levelling Adjusters ensure secure machine placement for production and allow you to move the machine if necessary.
	Advanced Printhead Technology includes a printhead protection system that detects media collision and automatic media height and head positioning for easy set-up and production.
	An Anti-Static Ionization System reduces static interference and increases print quality.

	A Side Table Control Station enables comfortable and convenient machine management— allowing accessible placement of PC workstation or laptop.
	VersaWorks 6 RIP Software is included with machine purchase and offers Roland DG Color System and Pantone® libraries, advanced tiling, nesting, variable data, and many more features to ensure quality print output.
	A 4-Quadrant Emergency Stop System in every corner of the machine with a gantry safety panel and detection beam increase operator safety.

Included VersaWorks 6 RIP Software

For optimum control, the EU-1000MF now supports VersaWorks 6 RIP Software. Simple to use, and powerful, this software includes advanced features and tools that help you manage the print process. It also simplifies the management of gloss and white ink layers, print layouts, and comes with built-in colour management tools that make reproducing specific colours easier than ever.

Download VersaWorks
for EU-1000MF Learn More
about VersaWorks

Create Value with Direct Printing

Introducing VersaOBJECT from Roland DG - a comprehensive solution that enables anyone to easily print directly onto 3D objects made of a variety of materials.

FIND OUT MORE

Specifications

Model		VersaOBJECT EU-1000MF
Media	Width	Max. 2,440 mm
	Length	Max. 1,220 mm
	Thickness	Max. 95 mm
	Weight	Max. 45 kg/m2
	Max. printing width/printing length (*1)	Max. 2,440 mm x 1,220 mm
Ink	Type	E-US
	Colours	6 colours (Cyan, Magenta, Yellow, Black, White, Gloss)
	Tank Capacity	2.5 L
	Bottle Capacity	1-Litre Bottles
	Configuration	4 Colour CMYK 6-Colour CMYKWhGl
Machine Weight		1,300 kg
Resolution		Max. 720 x 1,200 dpi
Included Items		Power cord, User's manual (Download), Software RIP (Download), USB Drive with PrintExp Software (Printer control software), Goggles, etc.

^*1 The maximum printing area can be extended to 2,440 mm x 1,220 mm.

Built to Build your business with the Best Warranty, Service and Support in the Industry

When you buy the VersaOBJECT EU-1000MF, you're not only investing in new technology, but you're also ensuring Roland DG's highest
standard of mechanical quality and reliability, combined with a superior level of service and support.
Your EU-1000MF industrial flatbed UV-LED printer also includes a One Year Trouble Free Warranty
that gives you added security and peace of mind with your machine.

GREENGUARD Gold

EUS inks are GREENGUARD Gold certified, meaning they meet strict standards of low chemical emissions making them ideal for indoor applications.

Protect Your Investment

Take your business forward with complete peace of mind thanks to Roland DG’s renowned post-sale service. Roland DG Care warranties cover you for much more than device maintenance.

Factory-trained service engineers
Quick installation and first-time set-up
Expert advice and training

Why Choose Roland DG?

People buy Roland DG equipment because they know it will do what they need it to do - and more. Our mission is to bring new opportunities to society through digital technology, and we aim to develop the most reliable solutions in the industry.

More than 40 years of trusted technical excellence.
Robust, flexible technology and repeatable results.
Unparalleled post-sales service and support.

Get in touch today and find out why Roland DG is the first choice for print businesses worldwide.
